IEC 61851-22 pdf download.Electric vehicle conductive charging system
1 Scope
This part of IEC 61 851 , together with part 1 , gives the requirements for a.c. electric vehicle charging stations for conductive connection to an electric vehicle, with a.c. supply voltages according to IEC 60038 up to 690 V. This standard does not cover all safety aspects related to maintenance. The scope of this part of IEC 61 851 does not cover box type assemblies with socket-outlets, installed for the purpose of delivering energy to the vehicle, which have no charging control functions.
2 Normative references
The following normative documents contain provisions which, through reference in this text, constitute provisions of this part of IEC 61 851 . For dated references, subsequent amendments to, or revisions of, any of these publications do not apply. However, parties to agreements based on this part of IEC 61 851 are encouraged to investigate the possibility of applying the most recent editions of the normative documents indicated below. For undated references, the latest edition of the normative document referred to applies. Members of ISO and IEC maintain registers of currently valid International Standards. IEC 60038:1 983, IEC standard voltages IEC 60068-2-1 :1 990, Environmental testing – Part 2: Tests – Tests A: Cold IEC 60068-2-2:1 974, Environmental testing – Part 2: Tests – Tests B: Dry heat IEC 60068-2-3:1 969, Environmental testing – Part 2: Tests – Test Ca: Damp heat, steady state IEC 60068-2-5:1 975, Environmental testing – Part 2: Tests – Test Sa: Simulated solar radiation at ground level IEC 60068-2-1 4:1 984, Environmental testing – Part 2: Tests – Test N: Change of temperature IEC 60068-2-30:1 980, Environmental testing – Part 2: Tests – Test Db and guidance: Damp heat, cyclic (1 2 + 1 2-hour cycle) IEC 60068-2-52:1 996, Environmental testing – Part 2: Tests – Test Kb: Salt mist, cyclic (sodium chloride solution) IEC 60068-2-75:1 997, Environmental testing – Part 2: Tests – Test Eh: Hammer tests IEC 60364-4-43:1 977, Electrical installations of buildings – Part 4: Protection for safety – Chapter 43: Protection against overcurrent IEC 60364-4-443:1 995, Electrical installations of buildings – Part 4: Protection for safety – Chapter 44: Protection against overvoltages – Section 443: Protection against overvoltages of atmospheric origin or due to switching Amendment 1 (1 998) 1 ) IEC 60439-1 :1 999 Low-voltage switchgear and controlgear assemblies – Part 1 : Type-tested and partially type-tested assemblies IEC 60529:1 989, Degrees of protection provided by enclosures (IP Code) IEC 60664-1 :1 992, Insulation coordination for equipment within low-voltage systems – Part 1 : Principles, requirements and tests IEC 60950:1 999, Safety of information technology equipment IEC 61 000-2-2:1 990, Electromagnetic compatibility (EMC) – Part 2: Environment – Compati- bility levels for low-frequency conducted disturbances and signalling in public low-voltage power supply systems IEC 61 000-3-2:2000, Electromagnetic compatibility (EMC) – Part 3-2: Limits – Limits for harmonic current emissions (equipment input current ≤1 6 A per phase) IEC 61 000-4-1 :2000, Electromagnetic compatibility (EMC) – Part 4-1 : Testing and measure- ment techniques – Overview of IEC 61 000-4 series
4 General requirements
The connection of electric vehicles can be made by one or more of the methods described in part 1 . The a.c. electric vehicle charging station may have one or more socket-outlets/vehicle connectors. The a.c. electric vehicle charging station shall be connected to the electric vehicle so that in normal conditions of use the equipment operates to reduce the risk of fire, electric shock or injury to persons, either indoors or outdoors. In general, this is achieved by fulfilling the relevant requirements specified in this standard and compliance is checked by carrying out all relevant tests. General requirements for the a.c. electric vehicle charging station can also be found in IEC 60439-1 .
5 Standard conditions for operation in service and for installation
The rated value of the a.c. supply voltage is up to 690 V. The equipment shall operate correctly within ±1 0 % of the standard nominal voltage (see IEC 60038). The rated value of the frequency is 50 Hz ± 1 % or 60 Hz ± 1 %. The ambient temperature range during charging may be between –30 °C and +50 °C and at a relative humidity of between 5 % and 95 %. NOTE National codes and regulations may require different operating temperature ranges.
